Description
dimensions: 4970*1655*2240mm
rated load capacity: 1100kg
rated power: 38kw
Product Feature
From moving sand and gravel to salt and snow, the B30 compact wheel loader is suited for all seasons — it’s the economical compact loader option perfect for any small landscaping, bulk and material handling, or snow removal jobs. Its skid-steer-style coupler makes it a versatile loader fit for multiple attachments. And whether you need to operate at faster speeds to clear snow, or at a slower pace for jobs that aren’t time-sensitive, the B30 loader provides the perfect balance with ground speeds up to 15 mph (24 kph). Its low-maintenance engine and basic features make it a simple, compact loader at an affordable price.
QUANCHAI 38KW, Tier 4f certified engine is designed for lower maintenance and features automatic, in-the-background regeneration with no DEF or DPF requirements
Manual powershift transmission provides precise gear selection
Joystick with integrated directional control switch allows for fingertip shifting and more intuitive loader control, and a separate third-function lever powers attachment hydraulics
Operator cab features A/C, AM/FM and USB radio, and is ROPS/FOPS approved with excellent 360-degree visibility for a ready-to-work operator environment
Skid-steer-style coupler with in-cab control simplifies attachment changes for ultimate versatility
General purpose skid-steer-style bucket with reversible bolt on cutting edges provides easy loading and longer bucket edge life
MYZG conventional axles with air-cooled, dry-disc brakes make servicing simple
Parameter
| Rated load capacity | 1100kg |
| Rated bucket capacity | 0.4m3 |
| Operating weight | 2560kg |
| Engine model | QUANCHAI /yunnei |
| Rated power | 38kw |
| Rated speed | 2400 r/min |
| Dimensions | 4970*1655*2240mm |
| Dump height | 3000mm |
| Dump distance | 600mm |
| Min.turning radius | 3180mm |
| Wheel base | 2350mm |
| Wheeltrack | 1330mm |
| Tyre size | 20.5-16 |
Detail
DIFFERENTIATED PRODUCTS
According to different applications, various attachments are for option, such as extra-large coal bucket, log fork, grain bucket and grass fork etc.
