Description
938E-1800kg-Wheel-Loader…
Operating Weight: 5270kg
Bucket Capacity: 1.2m³
Load Capacity: 1800kg
Product Feature
MYZG,938E,unloading height 3.55 meters, low fuel consumption, strong power, low noise, large torque, super shoveling force, the new generation of 938E luxury cab, large space, panoramic skylight, wide vision, high-grade aviation suspension seat, comfortable driving, relieve fatigue, the new generation of 938E wing cover, more convenient maintenance.
Parameter
| Rated load capacity | 1800kg |
| Rated bucket capacity | 1.2m3 |
| Operating weight | 5270kg |
| Engine model | Quanchai,Sida,Huadong,Yunnei, Xichai,Yuchai, Cummins
(EURO III / EURO V) |
| Rated power | 76kw |
| Rated speed | 2400 r/min |
| Dimensions | 6100*2060*2840mm |
| Dump height | 3560mm |
| Dump distance | 995mm |
| Min.turning radius | 2970mm |
| Tyre size | 16/70-20 |
Detail
RELIABILITY
· Quanchai,Sida,Huadong,Yunnei, Xichai,Yuchai, Cummins engine .The specific power-matching technology with P, S, E (heavy-load, medium-load, light-load) power control mode, which can be reasonably selected according to the operating conditions. Not only ensure the machine dynamic performance, but also reduce the energy consumption and improve the productivity
· It is equipped with ZL20 casting reinforced drive axle and large modulus spiral bevel gear and planetary gear. The main drive and hub reduction use dual seals which have good sealing effect, strong bearing capacity and high reliability.
· The heavy-duty front and rear frames use high-strength steel plates which applies with CAE finite element analysis technology. The structure is reasonable with strong bearing capacity and high reliability.
HIGH EFFICIENCY
· Optimum design of work device. Reasonable matching of hydraulic system. Short total time. High work efficiency
· The dual high-low speed reinforced transmission has great traction and strong power output High travel speed is suitable for long-distance transfer operations
· The bucket is designed according to large-size wheel loader’s concept, which has small insertion resistance and high full-load rate
COMFORT
· New appearance cab has large-size loader style. The dimension is increased and the operation space is large. Dual curved front glass gives you wide vision. No threshold design, equipped with luxurious mechanical suspension seat and comfortable ride
· Three-stage vibration reduction in engine, transmission, and cab. Low vibration, low noise, and more comfortable Digital stepping instrument panel and CAN data bus communication technology. High definition, complete functions, good human-machine interaction
· Newly-designed engine hood with beautiful appearance, frame structure, stable and reliable. Large opening door structure with wide maintenance space
Optional air conditioner and heater, providing drivers with a comfortable operating environment
DIFFERENTIATED PRODUCTS
According to different applications, various attachments are for option, such as extra-large coal bucket, log fork, grain bucket and grass fork etc.
